Zywell Authorised Distributor
WE’RE ZYWELL
Mdot Pos is a Zywell authorised distributor and supplier in Malaysia that specialises in Zywell Products. Get your Zywell product back working the way it should.
Our Zywell-trained technicians use Zywell-approved diagnostics and tools on every repair. And we only use genuine Zywell parts. This means that all of our repairs are Zywell-certified and backed by Zywell.
ZYWELL PRODUCT
ZYWELL-ZY58Z-Pos Printer
- Printing Method Direct Thermal Line
- Resolution 384 dots/line
- Print Speed 250 mm/sec
- Bluetooth
ZYWELL-ZY301-Pos Printer
- Printing Method Direct Thermal Line
- Resolution Max. 640 dots/line
- Print Speed 260 mm/sec
ZYWELL-ZY306-Pos Printer
- Printing Method Direct Thermal Line
- Resolution Max. 576 dots/line
- Print Speed 260 mm/sec
ZYWELL-ZY307-Queue Management Printer
- Printing Method Direct Thermal Line
- Resolution Max. 576 dots/line
- Print Speed 260 mm/sec
- There are 4 groups queu no for different service.
- Can be used as queue machine and receipt printer at the same time,no need switch any more.
ZYWELL-ZY805-Pos Printer
- Printing Method Direct Thermal Line
- Resolution Max. 576 dots/line
- Print Speed 260 mm/sec
ZYWELL-ZY901-Pos Printer
- Printing Method Direct Thermal Line
- Resolution Max. 640 dots/line
- Print Speed 260 mm/sec
ZYWELL-ZY906-Pos Printer
- Printing Method Direct Thermal Line
- Resolution Max. 576 dots/line
- Print Speed 250 mm/sec
ZY609-Barcode Printer
- Resolution 203 DPI
- Print Speed Min 50.8mm/s Max 152mm/s
- Print Width Min 48mm Max 80mm
- Barcode 1D & 2D
MP4600-Barcode Printer
| Printing Method | Direct Transfer |
| Resolution | 203DPI |
| Printing Width | 108mm |
| interface | U/U + BT |
| Print Speed | Max 152mm (6’’/s) |
| barcode | 1D & 2D |
| Power Supply | Input AC 100V-240V 50/60HZ Output DC 24V/25A |
| Detection | Thermal sensitive resistance, photoeletric sensor |
| Paper Type | Thermal Label Paper |
| Paper Width | 118mm |
| paper Thickness | 0.25mm |
| Roll Inner | Max. Ø110mm |
| Paper Off | Tear off |
| Processor | 32 bit CPU |
| Memory | 8MB Flash memory / 8mb sdram |
| Printing Head | 50km |
| Dimension | 224mm(L) X 180mm(W) X 161mm(H) |
| Weight | 1.4kg |
ZY812 -Pos Printer
| Printing Method | Direct Transfer |
| Print Speed | Max 260mm/s |
| Resolution | 203DPI |
| Printing Width | 72mm |
| interface | USB + LAN + SERIAL / USB + LAN + SERIAL+ BLUETOOTH |
| Input Buffer | 2MB |
| NV Flash | 256 kbytes |
| Function | With voice, sound and light alarm (optional) |
| Sensors | Print head temperature, paper presence, lid detection, paper jam, sound and light alarm (optional) |
| Paper Type | Thermal receipt paper |
| Paper Width | 58mm/80mm |
| paper Thickness | 0.06-0.08mm |
| Roll Inner | 83mm max |
| Paper Off | auto cut |
| Barcode | 1D and 2D |
| Power | AC 100V-240V 50/60HZ, DC24V/2.5A |
| Dimension | 165mm(L) X 128mm(W) X 115mm(H) |
| Weight | 1.6kg |
ZY861 -Pos Printer
| Printing Method | Direct Transfer |
| Print Speed | Max 260mm/s |
| Resolution | 203DPI |
| Printing Width | 72mm |
| interface | USB + LAN + SERIAL / USB + LAN + SERIAL+ BLUETOOTH |
| Input Buffer | 2MB |
| NV Flash | 256 kbytes |
| Function | With voice, sound and light alarm (optional) |
| Sensors | Print head temperature, paper presence, lid detection, paper jam, sound and light alarm (optional) |
| Paper Type | Thermal receipt paper |
| Paper Width | 58mm/80mm |
| paper Thickness | 0.06-0.08mm |
| Roll Inner | 83mm max |
| Paper Off | auto cut |
| Barcode | 1D and 2D |
| Power | AC 100V-240V 50/60HZ, DC24V/2.5A |
| Dimension | 165mm(L) X 128mm(W) X 115mm(H) |
| Weight | 1.6kg |
ZY3600-Barcode Printer
<
| Printing Method | Direct Thermal |
| Print Speed | Min 50.8mm/s max 152mm/s |
| Resolution | 203DPI |
| Port | USB + LAN + SERIAL |
| input Buffer | 2m |
| NV Flash | 4M |
| Sensors | Thermal sensitive resistance, Paper exists detection |
| Paper Type | Thermal label |
| Paper Thickness | 0.06 – 0.19mm |
| Paper Width | 25mm – 80mm |
| Roll Dia | 92mm max |
| Barcode | 1D ,2D |
| Power Input | AC 100V-240V 50/60HZ |
| Exportation | DC 24V/2.5A |
| Dimension | 186mm(L) X 143mm(W) X 136mm(H) |
| Weight | 1.5kg |
ZYQ821-Pos Printer
| Printing Method | Direct Transfer |
| Print Speed | Max 260mm/s |
| Resolution | 203DPI |
| Printing Width | 72mm |
| interface | USB + LAN + SERIAL / USB + LAN + SERIAL+ BLUETOOTH |
| Input Buffer | 2MB |
| NV Flash | 256 kbytes |
| Function | With voice, sound and light alarm (optional) |
| Sensors | Print head temperature, paper presence, lid detection, paper jam, sound and light alarm (optional) |
| Paper Type | Thermal receipt paper |
| Paper Width | 58mm/80mm |
| paper Thickness | 0.06-0.08mm |
| Roll Inner | 83mm max |
| Paper Off | auto cut |
| Barcode | 1D and 2D |
| Power | AC 100V-240V 50/60HZ, DC24V/2.5A |
| Dimension | 165mm(L) X 128mm(W) X 115mm(H) |
| Weight | 1.6kg |
